To Find Your Door Parts:
- Hover mouse anywhere within the blue squares on the door image.
- Click on the highlighted box to display the part numbers and links on the left-side box.
- Click on your part number in the left-side box to bring you to the page where you can order your part.
Model P11 & G11 Plus
Door Window
Upper Door Hinge Unit
Lower Door Hinge Unit
Gaskets
Gaskets
Eye-catching & Durable
This attractive and durable impact traffic door fills the need for a door that delivers good looks and durability in a lightweight door panel. It can be used in a wide variety of applications, including grocery, restaurant, retail, institutional and light industrial. The 11/16” thick door panel is constructed with a honeycomb polymer core and full perimeter internal expanded PVC framework. It is clad with textured, impact resistant ABS face sheets and features scratch-resistant acrylic 14” x 16” vision panels that are available in both standard and flush styles. These attractive, durable door panels are textured on both sides and operate on the Easy Swing Hinge System pioneered by Eliason more than fifty years ago, and still the smoothest-operating and most reliable hinge system on the market today. If your application requires full perimeter gasketing, specify model G11-Plus.
Specifications
- Door Classification: ABS traffic door
- Door Design: The door body is constructed of a honeycomb polymer core and full perimeter internal expanded PVC frame clad with textured, impact resistant ABS face sheets
- Face Sheet Material: Textured, impact resistant ABS
- Back Channel: Black powder coated, galvanized steel
- Optional: Impact plates, bumpers, and aluminum bumper strips
Construction
- Back Channel: 14 gauge galvanized, powder coated satin black
- Door Thickness: 11/16"
- Finish: 0.80 thick ABS
- Hinge: Eliason Easy Swing® Hinge System
- Window: 14" x 16" scratch-resistant acrylic set in black rubber molding
